2004 Arctic Cat 500 4x4 Automatic TBX Specifications

Vehicle Specifications

2004 Arctic Cat 500 4x4 Automatic TBX

• Front Brake Type
  Hydraulic Disc
• Rear Brake Type
  Disc
• Fuel Capacity (gal)
  4.8
• Fuel Capacity (l)
  18.1
• Carburetion Type
  Carburetor
• Digital Instrumentation
  Standard
• Wheelbase (in)
  58
• Wheelbase (mm)
  1473.2
• Cylinders
  1
• Displacement (cc)
  493
• Engine Stroke
  4-Stroke
• Engine Type
  Single-Cylinder
• Starter
  Electric / Pull
• Valve Configuration
  SOHC
• Generic Type (Primary)
  Utility
• Revision Status
  Upgraded
• MSRP
  6999
• Warranty (Months)
  6
• Tachometer
  Not Available
• Front Tire (Full Spec)
  AT 25 X 8-12
• Rear Tire (Full Spec)
  AT 25 X 11-2
• Primary Drive (Rear Wheel)
  Shaft
• Transmission Type
  Continuously Variable (CVT)
• Dry Weight (kg)
  336.6
• Dry Weight (lbs)
  742
