2006 50 Specifications

Vehicle Specifications

2006 Yamaha Raptor 125 50

• Front Brake Type
  Dual Sealed Drum
• Rear Brake Type
  Sealed Drum
• Fuel Capacity (gal)
  1.8
• Fuel Capacity (l)
  6.8
• Carburetion Type
  Carburetor
• Digital Instrumentation
  Not Available
• Wheelbase (in)
  40.6
• Wheelbase (mm)
  1031.2
• Compression Ratio
  10.0:1
• Cylinders
  1
• Displacement (cc)
  49
• Engine Stroke
  4-Stroke
• Engine Type
  Single-Cylinder
• Starter
  Electric
• Valve Configuration
  SOHC
• Generic Type (Primary)
  Youth
• Revision Status
  Carryover
• MSRP
  2199
• Warranty (Months)
  6
• Number Of Seats
  1
• Seat Height (in)
  24.3
• Seat Height (mm)
  617.2
• Tachometer
  Not Available
• Front Tire (Full Spec)
  Dunlop® AT 16 X 7-7
• Rear Tire (Full Spec)
  Dunlop® AT 16 X 8-7
• Number Of Speeds
  1
• Primary Drive (Rear Wheel)
  Shaft
• Transmission Type
  Automatic
• Dry Weight (kg)
  107.5
• Dry Weight (lbs)
  237
