2009 Yamaha C3 Base Specifications

Vehicle Specifications

2009 Yamaha C3 Base

• Front Brake Type
  Drum
• Rear Brake Type
  Drum
• Fuel Capacity (gal)
  1.2
• Fuel Capacity (l)
  4.5
• Carburetion Type
  Fuel Injected
• Digital Instrumentation
  Not Available
• Wheelbase (in)
  50.4
• Wheelbase (mm)
  1280.2
• Compression Ratio
  12.0:1
• Cylinders
  1
• Displacement (cc)
  49
• Engine Stroke
  4-Stroke
• Engine Type
  Single-Cylinder
• Starter
  Electric / Kick
• Valve Configuration
  SOHC
• Generic Type (Primary)
  Scooter
• Revision Status
  Carryover
• MSRP
  2099
• Warranty (Months)
  12
• Number Of Seats
  1
• Seat Height (in)
  28.9
• Seat Height (mm)
  734.1
• Tachometer
  Not Available
• Front Tire (Full Spec)
  120/90 R10
• Rear Tire (Full Spec)
  120/90 R10
• Primary Drive (Rear Wheel)
  Belt
• Transmission Type
  Continuously Variable (CVT)
• Dry Weight (kg)
  89.8
• Dry Weight (lbs)
  198
