2020 Arctic Cat Alterra 570 4x4 Specifications

Spec, Photos, and Model Information

Vehicle Specifications

2020 Arctic Cat Alterra 570 4x4

  • Front Brake Type
    Hydraulic Disc
  • Rear Brake Type
    Hydraulic Disc
  • Fuel Capacity (gal)
    5.7
  • Fuel Capacity (l)
    21.6
  • Carburetion Type
    Fuel Injected
  • Digital Instrumentation
    Standard
  • Wheelbase (in)
    52
  • Wheelbase (mm)
    1320
  • Cylinders
    1
  • Displacement (cc)
    545
  • Engine Stroke
    4-Stroke
  • Engine Type
    Single-Cylinder
  • Valve Configuration
    SOHC
  • Generic Type (Primary)
    Utility
  • Revision Status
    Carryover
  • Warranty (Months)
    12
  • Number Of Seats
    1
  • Tachometer
    Standard
  • Front Tire (Full Spec)
    Carlisle Trail-Pro AT 25 X 8-12
  • Rear Tire (Full Spec)
    Carlisle Trail-Pro AT 25 X 10-12
  • Primary Drive (Rear Wheel)
    Shaft
  • Transmission Type
    Continuously Variable (CVT)
  • Dry Weight (kg)
    317
  • Dry Weight (lbs)
    699
