2023 CSC SG250 San Gabriel Specifications

Spec, Photos, and Model Information

  • Start Price
    $2,495
  • Displacement (cc)
    229.5
  • Horsepower (bhp)
    16.1
  • Torque (Ft Lbs)
    13.5

Vehicle Specifications

2023 CSC SG250 San Gabriel

  • Front Brake Type
    Disc
  • Rear Brake Type
    Disc
  • Fuel Capacity (gal)
    4
  • Fuel Capacity (l)
    15.1
  • Carburetion Type
    Carburetor
  • Digital Instrumentation
    Not Available
  • Wheelbase (in)
    50.8
  • Wheelbase (mm)
    1397
  • Compression Ratio
    8.7:1
  • Cylinders
    1
  • Displacement (cc)
    229.5
  • Engine Stroke
    4-Stroke
  • Engine Type
    Single-Cylinder
  • Horsepower (bhp)
    16.1
  • Starter
    Electric / Kick
  • Torque (Ft Lbs)
    13.5
  • Valve Configuration
    SOHC
  • Generic Type (Primary)
    Standard
  • Revision Status
    Carryover
  • MSRP
    2495
  • Warranty (Months)
    12
  • Number Of Seats
    2
  • Seat Height (in)
    26
  • Seat Height (mm)
    660.4
  • Tachometer
    Standard
  • Front Tire (Full Spec)
    90/70-R17
  • Rear Tire (Full Spec)
    120/70-R17
  • Number Of Speeds
    5
  • Primary Drive (Rear Wheel)
    Chain
  • Transmission Type
    Manual
