2023 EPS XT-R Specifications

Vehicle Specifications

2023 Yamaha Grizzly 125 EPS XT-R

• Front Brake Type
  Dual Hydraulic Disc
• Rear Brake Type
  Dual Hydraulic Disc
• Fuel Capacity (gal)
  4.8
• Fuel Capacity (l)
  18.2
• Carburetion Type
  Fuel Injected
• Digital Instrumentation
  Standard
• Wheelbase (in)
  49.2
• Wheelbase (mm)
  1249.7
• Compression Ratio
  10.0:1
• Cylinders
  1
• Displacement (cc)
  686
• Engine Stroke
  4-Stroke
• Engine Type
  Single-Cylinder
• Starter
  Electric
• Valve Configuration
  SOHC
• Generic Type (Primary)
  Utility
• Revision Status
  Carryover
• MSRP
  12399
• Warranty (Months)
  6
• Number Of Seats
  1
• Seat Height (in)
  36.6
• Seat Height (mm)
  929.6
• Front Tire (Full Spec)
  Maxxis® Zilla AT27 x 10 - 14 MU01
• Rear Tire (Full Spec)
  Maxxis® Zilla AT27 x 10 - 14 MU01
• Primary Drive (Rear Wheel)
  Shaft
• Transmission Type
  Continuously Variable (CVT)
